LED Configuration Guide & Setup

Configuring an LED wall involves determining your viewing distance to select the right pixel pitch, choosing cabinet sizes (e.g., 500x500mm or 1000x500mm), defining your screen dimensions, and connecting a compatible control processor such as NovaStar. CMG Visuals provides full project consultation, on-site installation, and technical support to guide you through every step of this process.

On a standard LED module or panel, the cathode side connects to ground. In LED video wall systems, polarity is managed internally by the driver ICs on each panel, so installers follow the manufacturer's wiring diagrams and control system (e.g., NovaStar) cabling guides rather than wiring individual LEDs manually. Always consult your panel's technical documentation.

Pixel pitch depends on your viewing distance. For close-range indoor viewing such as corporate boardrooms or church sanctuaries, finer pitches like P1.5 or P1.9 deliver sharp detail. For larger venues or outdoor digital signage where audiences are farther away, coarser pitches like P2.6 or higher are appropriate and more cost-effective.

Yes. CMG Visuals offers specialty LED configurations including curved, 90-degree corner, floor-standing, and cylindrical displays. Flexible modular panels allow seamless curved surfaces without visible panel boundaries, making them ideal for trade show booths, DJ setups, broadcast studios, and architectural feature walls in corporate lobbies or event venues.

Fixed LED screens are permanently installed in a venue using rigid cabinet systems optimized for long-term performance, such as the 101 and 201 F Series. Rental screens use lightweight modular frames designed for fast assembly and disassembly, like the 101 and 201 R Series, making them ideal for touring events, temporary installations, and one-time activations.

CMG Visuals LED displays are compatible with NovaStar processors and similar LED controllers. These systems manage signal processing, brightness calibration, and content mapping across the full video wall. CMG Visuals' NovaStar-certified engineers handle controller setup, signal routing, and calibration as part of their installation and configuration services.
